COGO

| |

• COGO (Coordinate Geometry) commands allow to perform different operations directly in the field with GNSS and TPS instruments.

• For example:

  • Creating points according to different methods.

  • Get information related to positions of the points such as distances or angles.

  • Get information related to the current position of the receiver.

In the tab is called Check.

• Inverse: to quickly calculate distance and other information between two points.

• Distance: calculates the distance and other information from different entities.

• Reference line: calculates the distance and other information from a reference line and the current position.

• Alignment & offset: calculates a coordinate along a reference element at certain distance and offset.

• Intersection: calculates a coordinate on an intersection using different methods.

• Area subdivision: allows to divide an area according to different rules.

• Check planes: how to check horizontal, vertical and sloped planes.

• Area & Length: calculates areas and perimeters.

• Move, Rotate & Scale: how to use the function to manually or by common points transform points and drawings.

• BIM surface: how to stakeout BIM models.

• Traverse calculation: how to perform a traverse calculation in the field and adjust the stations.

Video tutorials
Distances How to use the Distances functions to quickly calculate distance, azimuth and other information between two coordinates.	Quick distance How to use the quick distance function to report distance and other information between coordinates.
Reference line How to use the reference line function to stakeout using lines and arcs as reference.	Intersection How to calculate new coordinates using different intersection methods.
Alignment and Offset How to calculate new coordinates using an alignment and an offset.	Area subdivision How to use the area subdivision function to divide a closed area or parcel using different rules.
Traverse calculation How to calculate a traverse and generate a report.	Check planes How to use the function check planes to verify an horizontal, sloped or vertical plane using GNSS or TPS.
Area and Length How to use the function area and lenght to quickly measure and calculate an area and perimeter.	Move Rotate Scale manual entry How to use the move, rotate and scale function to edit data entering the amount of shift, rotation and scale to apply.
Move rotate scale align points How to use the move, rotate and scale function to edit data entering source and target points.
